JDY-33 Dual Mode Bluetooth Module | HC-05/06 Compatible
Original price was: ₹225.00.₹120.00Current price is: ₹120.00.
| Model | JDY-33 |
| Bluetooth Version | Bluetooth 3.0 SPP + BLE4.2 |
| Communication Interface | UART |
| Operating Temperature Range | -40°C to 80°C |
| Operating Voltage | 1.8 – 3.6V |
| Receiving Sensitivity | -96dbm |
| Transmission distance | 30M |
| Transmit Power | 6db |
| Working Current | 6.5mA |
| Working Frequency | 2.4GHZ |
| Length | 31 mm |
| Height | 3 mm |
| Width | 16 mm |
Only 1 left in stock
JDY-33 Dual Mode Bluetooth Module | HC-05/06 Compatible
JDY-33 Bluetooth 3.0 SPP + BLE-based design, which can support Windows, Linux, Android, IOS Transparent data transmission. JDY-33 is a classic Bluetooth + BLE dual-mode Bluetooth, can communicate with Bluetooth-enabled computers (desktop, notebook), mobile (android), IOS.
Features:
- Model: JDY-33
- Communication Interface:UART
- It has a built-in PCB antenna.
Application:
- Bluetooth POS machines
- Thermal printer
- Intelligent home control
- Car ODB testing equipment
- Bluetooth transparent transmission of various product applications
Package Includes:
1 x JDY-33 Dual Mode Bluetooth SPP SPP-C compatible with HC-05/06 slave Bluetooth 3.0 Module.
| Weight | 10 g |
|---|
