Category: IOT Module for DIY
Showing all 6 results
-
1 Channel 5V Relay Module
Original price was: ₹55.00.₹33.00Current price is: ₹33.00.Add to cartFeatures :
- 1 channel relay board
- Operating Voltage 5V
- Pull-down circuit for avoidance of malfunction
- Power supply indicator lamp
- Control indicator lamp
- Indicator for Relay output status
- Max Current : 20mA
- Relay Contact Current Capacity at AC250V: 10A
- Relay Contact Current Capacity at DC5V: 10A
- One normally closed contact and one normally open contact
- Triode drive, increasing relay coil
- High impedance controller pin
- Can Be controlled various appliances & other Equipment With Large current.
- Standard TTL Level logic controlled (AVR, Arduino, 8051, PIC, ARM)
- The module is compliant with international safety standards, control and load areas isolation trenches;
* Product Image is shown for illustrative purposes only and may differ from actual product.
-
2 Channel 5V Relay Module with Optocoupler
Original price was: ₹80.00.₹62.00Current price is: ₹62.00.Add to cartSpecification:
- High current relay, AC250V 10A, DC5V 10A
- 2 LEDs to indicate when relays are on
- Works with logic level signals from 3.3V or 5V devices
- Opto isolation circuitry
* Product Images are shown for illustrative purposes only and may differ from actual product.
-
4 Channel 5V Relay Module with Optocoupler
Original price was: ₹250.00.₹118.00Current price is: ₹118.00.Add to cartFeatures:
- Channel: 4 channel
- Relay Operating Voltage: 3.3V to 5V
- High impedance controller pin
- DC or AC signal, control, you can control the 220V AC load.
- There is a normally open and one normally close contact.
- Triode drive, increasing relay coil
- Pull-down circuit for avoidance of malfunction
- Power supply indicator and Control indicator lamp
- Power supply and relay instructions, lit, disconnect is off.
- Input signal, signal, common Terminal and start conducting.
- Useful for appliance control.
- One normally closed contact and one normally open contact
- The module is compliant with international safety standards, control and load areas isolation trenches.
* Product Image is shown for illustrative purposes only and may differ from actual product.
-
NODEMCU – ESP8266 Wifi Development Board
Original price was: ₹200.00.₹150.00Current price is: ₹150.00.Read moreNodeMCU is a IoT Module based on ESP8266 wifi Module. NodeMCU uses Lua Scripting language and is an open source Internet of Things (IoT) platform. This modules has CH340g USB to TTL IC.
Features of Node-MCU IoT Module:
- Open source IoT Platform
- Easily Programmable
- Low cost & Simple to Implement
- WI-FI enabled
Specification of Node-MCU IoT Module:
- It is based on ESP8266, integrates GPIO, PWM, IIC, 1-Wire and ADC all in one board.
- Power your development in the fastest way combining with NodeMCU Firmware!
- USB-TTL included, plug&play
- 10 GPIO, every GPIO can be PWM, I2C, 1-wire
-
PIR Motion Detector Sensor Module
Original price was: ₹75.00.₹54.00Current price is: ₹54.00.Add to cartFeatures:
- Detection Distance: 3 to 7m (can be adjusted)
- Delay Time: 5 to 200s (Can be Adjusted, Default 5s +/- 3%)
- Blockade time: 2.5s (Default)
- Work temperature: -20 ~ +80°C
- Dimension: 3.2cm x 2.4cm x 1.8cm (Approx)
- Color: White + Green OR White + Blue
- Infrared Sensor with Control Circuit Board
- The Sensitivity and Holding Time Can be Adjusted
- Working Voltage Range: DC 4.5V- 20V
- Current Drain: <60uA
- Detection Range: <140°
- Voltage Output: High/Low level Signal: 3.3V TTL output
- Sensitive Setting: Turn to Right, Distance Increases (About 7M); Turn to Left, Distance Reduce (About 3M)
- Time Setting: Turn to Right, Time Increases (About 200S); Turn to Left, Time Reduce (About 5S).
* Product Image is shown for illustrative purposes only and may differ from actual product.
-
W1209 Digital Temperature Controller Thermostat Module
Original price was: ₹120.00.₹87.00Current price is: ₹87.00.Add to cartW1209 Module Specifications:- Input Power (DC): 12V
- Measuring Inputs: NTC (10K 0.5%)
- Waterproof Sensor: 0.5M
- Output: 1 Channel Relay Output,
- Capacity: 10A
- Temperature Control Range: -50 ~ +110 C
- Resolution at -9.9 to 99.9: 0.1 C
- Resolution at all other temperatures: 1 C
- Measurement Accuracy: 0.1 C
- Control Accuracy: 0.1 C
- Refresh Rate: 0.5 Seconds
